Mobile Chemical Storage

Mobile Chemical Storage

Mobile Chemical Storage

Mobile Chemical Storage

Product Features

  • Mobile Chemical Storage is a specifically customized module for storing of hazardous goods such as chemicals, paint, toxic gases and hazardous waste. It is vastly used in various industries such as petrochemical, chemical, biomedical, pharmaceutical, waste management, research institutes, universities and places where hazardous goods and waste are being stored.
  • It is designed to withstand a blast rating of 10psi or even higher rating. To ensure a quick venting release and protection of the structure’s facility, explosion venting wall and/or door are installed on the safe side.
  • All electrical equipment is ATEX/IECEx certified and suitable for Zone 1 or 2 application.
  • The module comes with both active and passive fire protection systems. The active fire protection includes an automatic fire suppression or manual fire extinguishing system, while passive fire protection has up to 4-hour fire rated wall, 1.5 hours of fire insulation and other fire-rated equipment/system.

FEATURES

  • Zone 1

  • Zone 2

  • Safe Zone

AUTHENTICATION

  • DNV 2.7-1

  • FM Class Number 4440

  • CE

  • UL

  • ATEX

  • IECEx

SPECIFICATIONS

model Overall dimensions(mm) dead-weight(kgs) load(kgs) All Up(kgs) Remarks Picture
ChemSafe7530 7500x5000x3000 8000 7500 15500 / view picture
ChemSafe40ftST 12192x2438x2591 9500 10500 20000 / view picture
ChemSafe20ftHH 6058x2438x2896 7200 6800 14000 / view picture
ChemSafe20ftST 6058x2438x2591 6000 6000 12000 / view picture
ChemSafe6030 6000x3000x3000 6500 7500 14000 / view picture
