Product Center

Cargo Basket

Offshore Special Containers

Product Features

  • ISO 10855 & DNV 2.7-1;
  • Lightweight design but more loading capability;
  • Painting or H.D.G as protective manner;
  • 4-leg wire rope lifting sling equips as option;
  • Stacking point,Interior D-ring and Exterior tag line;
  • Roof Luminous marking;
  • Inner V-shape support, or strip winch as option;
  • Other customized sizes are available.

AUTHENTICATION

  • DNV 2.7-1

  • LR or DNV

SPECIFICATIONS

model Overall dimensions(mm) dead-weight(kgs) load(kgs) All Up(kgs) Remarks
20ft Bkt 6300x1500x1500 2000 8000 10000 /
38ft Bkt 11790x1192x1105 2600 10000 12600 /
45ft Bkt 13916x1192x1105 3500 10000 13500 /
48ft Bkt 14830x1192x1105 3650 10000 13650 /
55ft High Bkt 17070x1520x1830 5700 10000 15700 /
65ft Bkt 20120x1520x1215 5500 13500 19000 /
75ft Bkt 23160x1520x1215 6500 12500 19000 /
