E/C-House

E-House

E-House

E/C-House

Product Features

  • Designed after DNV 2.7-2 and 2.7-3 and IEC60079-13.
  • Available in various sizes for customization with maximum size of 12.5 (L) x 6.5 (W) x 4.5 (H) in meter of a single modular
  • Module could be in a single, multiple or stack manner
  • It could be designed as an unmanned or manned Instrument Enclosure
  • Various equipment and systems such as CCR cabinet, VESDA system, UPS, purge & pressurization system, marine air conditioning system and others upon request
  • Suitable for harsh environment
  • Designed for severe weather condition from -20°C to +55°C

FEATURES

  • Zone 1

  • Zone 2

  • Class1

  • Division 2

AUTHENTICATION

  • DNV2.7-2

  • DNV2.7-3

  • NORSOK Z-015

  • NORSOK C-002

  • NORSOK S-002

  • BS 476

SPECIFICATIONS

model Overall dimensions(mm) dead-weight(kgs) load(kgs) All Up(kgs) Remarks
DMT45IE 12000x4500x4000 20000 12000 32000 /
DMT65IE 12000x6500x4000 26000 14000 40000 /
