- DNV2.7-1 / DNV 2.7-2 / IEC60079-13,
- Appropriate for hazardous area: Zone 1 / Zone 2
- A60 rated, conforming to SOLAS, 2009
- Fire and gas control panel
- Operation temperature range: -20℃~ +55℃
- Supply voltage: 380~600Vac
- Supply frequency: 50/60 Hz
- Operation pressure: 50~75Pa
- HVAC system
- Customized furniture
| Model | Exterior(mm) | T.W.(Kgs) | Payload(Kgs) M | MGW(Kgs) |
20FT Mud Logging | 6058x2700x2800 | 9500 | 1000 | 10500 |
29FT Mud Logging | 8900x2700x2800 | 13500 | 1500 | 15000 |
40FT Mud Logging | 12192x2700x2800 | 17000 | 1500 | 18500 |
Other sizes and configurations may be supplied on request
